neoECU AVB/TSN

Device Specifications

  • Power supply: 4.5V – 40V operation
  • Temperature range: -40°C to 85°C
  • One-year limited warranty
  • Fully-isolated USB with Microsoft-certified USB drivers
  • Dimensions: 1.56″ x 4.42″ x 7.34″  (3.98 cm x 11.22 cm x 18.65 cm)
  • Weight: 1.31 lb (0.595 kg)


Network Specifications

  •  Ethernet configurations (mutually exclusive):
    • 100BASE-T1 endpoint (2-wire)
    • 1000BASE-T endpoint (8-wire, limited to 480 Mbps)
  • CAN (2 channels):
    • 1x CAN FD
    • 1x CAN FD/SW/LSFT

Supported Media Formats

  • Video: IEC 61883-6 (H264, 720p @ 30 FPS)
  • Audio: IEC 61883-4 / AAF
  • Firmware upgradeable to support additional formats

Supported Interfaces

  • 1x HDMI output
  • 2x analog audio in (mini jack)
  • 8x analog audio out (mini jack)
  • USB device (PC interface)
  • USB host (camera)
  • SD card slot

* Specifications subject to change. Please contact Intrepid for the latest information.
