RAD-IO2-BADGE
Low-Cost Analog Input and Digital Output DeviceDemo Board For Multichannel Analog Measurement
The RAD-IO2-Badge is a demonstration platform that can measure multichannel analog input and digital output on a single low-cost device. The device mimics the RAD-IO2-AIN and RAD-IO2-PWRRLY.
Open Source API for Python, Javascript and C++
Using Intrepid open source APIs, RAD-IO2-Badge can measure eight analog inputs with six 0-5V analog channels, potentiometer, and temperature sensor. This device can be used to simulate a relay module with LEDs as well as output four digital 0-5V channels. The RAD-IO2-Badge demonstrates how easy it is to get started with Intrepid Analog DAQ tools like RAD-IO2-AIN and RAD-IO2-PWRRLY.
Key Features
- 8 Analog inputs
- 6 Analog 0-5V input channels
- 1 connected to Potentiometer
- 1 connected to a temperature sensor
- 4 Digital 5V output channels
- 4 LEDs for relay module simulation
- 12-Bit ADC (Analog to Digital Converter)
- USB Type C connector for power and configuration
- Through-hole per channel for optional solder connection
- Push-in mating connector (Phoenix Contact 1778858)
- Open source Python, C++ and JavaScript example files and APIs at www.github.com/intrepidcs
All pictures shown are for illustration purpose only. Actual product may vary due to product enhancement.
